Flat Shaped Wire: Cross-Sections, Edges & Tolerances

Flat shaped wire with precise cross sections customizable materials and smooth finish for automotive electronics and hardware

A useful flat shaped wire specification defines the section, edges and lengthwise shape separately. Width and thickness can be within tolerance while a burr, sideways curve or twist still affects feeding, forming or assembly.

Start with the feature that matters to the next operation:

  • Fit: the section dimensions and any profile features that locate in a slot, guide or mating part.
  • Edges: the radius, corner detail or burr condition that affects contact, handling or bending.
  • Lengthwise shape: how the wire curves or rotates over the length relevant to the process.
  • Acceptance: where, how and in what condition those features will be measured.

If material selection is still open, use our flat wire material selection guide. This article focuses on turning the required profile into clear drawing and inspection requirements.

Dimensions, Edges and Shape Are Different Requirements

Fullgreat’s flat wire processing includes rolling, slitting and edge conditioning. The section, edge finish and overall shape each need their own acceptance criteria; a single description such as “precision wire” does not identify which feature controls your application.

Nominal Size, Tolerance and Measurement Position

The nominal dimension is the target size. Its tolerance defines the permitted variation. Width and thickness therefore need separate limits where both affect fit. A thickness requirement alone does not control the width, corner shape or burr.

Measurement position matters, especially near rounded corners or raised edges. Decide whether a dimension describes the main section or the maximum envelope including an edge feature. Contact instruments need measuring faces and force suited to the material and section; optical methods may help assess a profile where direct contact does not capture the required detail.

Edge Radius, Corner Break and Burr

These terms describe different features:

  • Edge radius: a defined curved transition. Identify the relevant edge and radius where it affects fit or forming.
  • Corner break: a local removal of the sharp corner, such as a small chamfer or radius. It does not necessarily create a fully rounded edge.
  • Burr: a raised lip or projection left by cutting. Its height, location and direction can matter even when the main section dimensions are correct.

For example, an edge that touches insulation may need a different acceptance requirement from an edge that locates against a guide. Identify the functional edge rather than relying on a general phrase such as “smooth finish.”

Straightness, Camber, Coil Set and Twist

A local cross-section does not describe the shape of a longer sample. Distinguish the condition you need to control:

  • Straightness: how closely a specified line follows a straight path over an evaluation length.
  • Camber: sideways curvature, viewed along the broad face of a flat section.
  • Coil set: retained lengthwise curvature associated with having been wound into a coil.
  • Twist: rotation of the section about its length, changing the orientation of the broad face.

Flatness describes a surface rather than a single line. A flatness check and a width check answer different questions. For flexible or coiled material, the sample length, support arrangement and whether it is free or restrained can change the observed result. Include those conditions with any shape limit.

Make the Inspection Method Part of Acceptance

A useful inspection plan connects each requirement to a repeatable check:

  1. Identify the feature: width, thickness, edge detail, a profile feature or a particular shape condition.
  2. Define the sample: its location, evaluation length and whether it is taken from coil, spool or cut material.
  3. Define the setup: orientation, support, restraint and measuring method appropriate to the feature.
  4. Record the result against the limit: use the drawing revision and acceptance criteria for the order, with sampling coverage defined for the supply.

A single reading describes that measurement position. Additional sampling is needed when the requirement concerns variation along a coil or across a batch. The scope should reflect the feature being controlled rather than an assumed universal sample count.

Material Condition and the Finished Profile

Fullgreat’s flat wire range includes stainless steel, aluminum, copper, iron and composite copper. This page addresses profile requirements; material and temper choices belong alongside the drawing because they affect forming and handling.

Distinguish acceptance of the supplied wire from acceptance after bending, stamping or joining. If the finished component must retain a dimension or functional property, assess it after the relevant operation. Passing an incoming section check does not establish the result after further forming.

Flat Sections and More Complex Profiles

Flat and Rectangular Wire

For a flat section, the drawing normally starts with width and thickness, then adds the edge and shape requirements needed by the component. If the broad face must remain in a particular orientation during feeding, identify that requirement separately from size.

Our flat wire specifications and supply options cover the current material range, dimensions and quotation information.

Profiles with Additional Features

A step, groove, projection or other individual feature needs its own definition. Overall width and thickness may be correct while a locating feature is in the wrong position. Show its size and relationship to the surfaces used for location or assembly.

For a non-standard section such as an H, U, T, Z or L profile, use our custom shaped metal profiles enquiry route with the cross-section drawing. Include the material and required cut length or supply format with the drawing.

Using Inspection Findings to Investigate a Production Problem

Consider flat wire that measures within its width and thickness limits but catches in a feeding guide. This is an illustrative inspection sequence:

  • Check where contact occurs. An edge catching at one side may direct attention to a burr or corner feature.
  • Check the section over the relevant length. Sideways curvature or changing face orientation may affect tracking even when local dimensions are acceptable.
  • Compare with the setup. Guide clearance, alignment and restraint also affect feeding. Observe the material and equipment together before assigning the cause.

Record the observation, then connect it to the feature and method that need checking. Tightening every dimensional tolerance may add requirements without controlling the actual problem.

For zipper-related manufacture, first distinguish ordinary flat wire from a dedicated tooth or stop-wire profile. The required raw-material cross-section and tooling arrangement are more informative than the finished zipper size alone.

Frequently Asked Questions

Does “Burr-Free” Fully Define the Required Edge?

It does not define a corner radius or rounded-edge geometry. For an edge-critical part, identify the required edge feature and how any remaining projection will be assessed. This makes the requirement more useful than an unqualified finish description.

Why Can Two Inspections Give Different Results?

First compare the measured feature, sample position, instrument setup, orientation and restraint. One inspection may assess the main section while another includes a burr, or one may restrain a sample that the other measures freely. Align the methods before treating the difference as a change in the material.

What Should Accompany a Profile Sample or Quotation Request?

Include the drawing revision, material and condition if selected, main dimensions and quantity. Add the critical edge or shape requirement and any defined inspection conditions. A sample or photograph of a feeding or forming problem can help explain which feature matters; the drawing and acceptance criteria remain the specification.


Use the flat wire product page for rectangular wire requirements or the custom profile page for a more complex section. Include the geometry and the next manufacturing operation so the enquiry can be matched to the appropriate supply form.
